Details

---

SPF 6000ES PLUS

• Plug-and-Play terminal for PV port
• Dual MPP TRACKERS
• Maximum PV input voltage up to 500VDC
• Configurable grid or solar input priority
• Parallel for scalability
• Dust-proof filter for harsh encironment
• Two AC input terminals with integrated transfer switch



Datesheet	SPF 6000ES Plus
Battery Voltage	48VCD
Battery Type	Lithium/Lead-acid
Inverter Output
Rated Power	6000VA/6000W
Parallel Capability	Yes, 6units maximum
AC Voltage Regulation(Battery mode)	230VAC +- 5% @ 50/60Hz
Surge Power	12000VA
Efficiency(Peak)	93%
Waveform	Pure sine wave
Transfer Time	10ms typical, 20ms max
Solar Charger
Maximum PV Array Power	8000W
MPPT Range @ Operating Voltage	120VDC ~ 450VDC
Number of Independent MPPT Trackers/ Strings Per MPP Tracker	2/1
Max. input current per MPP tracker	16A
Maximum PV Array Open Circuit Voltage	500VDC
Maximum Solar Charge Current	100A
AC Charger
Charger Current	80A
AC Input Voltage	230VAC
Selectable Voltage Range	170-280 VAC(For Personal Computers);90-280 VAC(For Home Appliances)
Frequency Range	50Hz/60Hz (Auto sensing)
Physical
Protection Degree	IP20
Dimension(W/H/D)	460/395/132mm
Net Weight(kgs)	13.5
Operating Environment
Humidity	5% to 95% Relative Humidity(Non-condensing)
Altitude	＜2000m
Operating Tempersture	0°C - 55°C
Storage Tempersture	-15°C - 60°C

If you have any need, please feel free to contact us.
