Details

---

Product Display

---

Safe and Reliable

• New Class A high-reliability lithium iron phosphate battery, green and environmentally feiendly
• Intelligent integrated BMS, all-round protection strategy and fault detection

System Services

• Support for viewing real-time deta through the app
• LCD display, dynamic display of system opersting status data

Technical Features

• Support off-grid/hybrid output
• Multiple charging and discharging modes are available

Full Functioning

• No matching and commissioning required, easy to install
• Up to two systems in parallel, with dual storage and output

Product Parameters

---

Inverter module	INV05KLP1
Output
Rated output power	5,000W
Maximum peak power	10,000VA
Motor load capacity	4HP
Wave form	PSW(Pure Sine Wave)
Rated output voltage	220V ac(single phase)
Maximum parallel capacity	2 units(up to 10KW)
Output mode	off-grid/hybrid
Solar input
Types of solar charging	MPPT
Macimum solar array power	5,500W
Maximum solar open-circuit voltage	550Vdc
Grid/generator inputs
Input voltage range	90~280Vac
Bypass overload current	40A
Battery charging
Maximum solar charging current	100A
Maximum grid/generator charging current	60A
Routine
Dimensions(LxWxHmm)	400x580x145
Weight(Kg)	~18

Battery module	PC-AIOV05B
Battery power	5.12KWh
Rated capacity	100Ah
Battery type	Square LFP
Cycle life	≥6000（80% DOD, 0.5C, 25°C）
Maximum parallel capacity	4 units(max. 20.48KWh)
Dimensions(LxWxHmm)	480x580x145
Weight(Kg)	~45
Standard	UN38.3, MSDS, IEC62619:2017, EN IEC61000-3-2, EN IEC61000-6-1, RoHS

Battery Features

---

• Original Class A high-reliability lithium iron phosphate battery, green and environmentally friendly
• Intelligent integrated BMS, all-round protection strategy and fault detection
• Supporting off-geid/hybrid output
• Multiple charging and discharging modes are available
• Play and plug design, easy to install
• Up to two systems in parallel, with dual storage and output
• Supporting for monitoring real-time data through the app
• LCD display, dynamic display of system operating status data
