Product Display

---

Safe and reliable

• The new A-grade lithium ion phosphate battery cell has high safety and reliability.
• The charging and discharging efficiency is high, and the number of cycles is more than 6000 times.

Technical features

• Modular design, can be expanded at any time to increase the energy of the system.
• It  supports up to 15 batteries in parallel.

System services

• It is compatible with most inverters on the market, and has strong flesibility in intelligent matching.
• It supports RS485 and CAN communication.

Full functioning

• Multi-function design, ON/OFF switch control output.
• The LCD display monitors the operating status in real time.

Feature Description

---

Product Description

---

Product Decription	Product parameters
Product model	SR15S100BL-V	SR16S100BL-V	SR16S200BL-V	SR16S200BL-V(T)
Cells in series	15S	16S	16S	16S
Rsted energy(kwh)	4.8	5.12	10.24	10.24
Rated voltage(V)	48	51.2	51.2	51.2
Charging voltage(V)	54.75	58.4	58.4	58.4
Discharge cut-off voltage(V)	40	42	42	42
Standard Charge Current(A)	20	20	40	40
Maximum Charging Current(A)	100	100	100	100
Maximum Discharge Current(A)	100	100	100	100
Cycle life	≥6000 times @ 80% DOD,25°C
Methods of Communication	RS232/RS485/CAN
Charging temperature	0~60°C	0~60°C	0~60°C	0~60°C
Discharge temperature	-10~65°C	-10~65°C	-10~65°C	-10~65°C
How it is displayed	LCD display	LCD display	LCD display	LCD display
Product Dimensions(LxWxHmm)	445x170x560	445x170x560	445x206x675	500x155x800
Net Weight(Kg)	41	43	89	90
Packing Dimensions(LxWxHmm)	632x512x255	632x512x255	755xx525x395	880x580x345
Gross Wight(Kg)	43	45	104	105
